An assortment of utilities to add maximum modulation capabilty to any system in a small space. Consisting of a white noise source, simple low-frequency oscillator, and a sample-and hold, the three circuits are normalled together to provide a wealth of modulation waveforms, including triangle, square, noise, and stepped random. The three components of this module may also be used completely independent of each other, if desired.

This device is part of the IRON CURTAIN ELECTRONICS system and is created in collaboration with Vladimir Kuzmin, the designer of the original POLIVOKS synthesizer. The module uses an original Russian transistor as a white noise source, to preserve the character of the Polivoks design.

specifications

Positive current draw: + mA

Negative current draw: - mA

Module depth behind panel: ?? mm (skiff friendly)

Panel size: 6HP

documentation

coming soon
