Standalone Stereo Multi Effects Processor

The ’MFX Pedal’ brings all the effects and functionality of our popular Eurorack MFX module to both guitars and synths in standalone form with 18 different fully featured effects programs and additional MIDI, Knob and Expression pedal control, tap tempo, an optional analogue gain stage and true relay (or DSP) based bypass.

Inspired by our favourite classic hardware effects processors, the MFX incorporates DSP effect technologies from the dawn of digital effects in the 70s to the present day. Reshape sounds with the distortion and dynamics engines. Bend time space and pitch with multiple feature rich reverb and delay engines. Modulate signals with the flexible panner, frequency shifter, and range of ensemble effects. Fracture sounds with the one of a kind granular and glitch engines.

The MFX Pedal user interface is designed to be familiar, quick and easy to use. Each program contains a wide range of controllable parameters both directly editable or freely assigned to knobs, MIDI or expression control. Each program includes factory presets as well as the ability to store and recall user presets. All states are preserved across power cycles.

Available for the first time outside of modular, the MFX pedal easily brings the character and uniqueness of ALM effects to your guitar rig, DAWless setup, mixer effects send or synth collection.

Feature list

→ A large varied collection of 18 effects programs, all with numerous controllable parameters.

Effect parameters freely assignable to panel knobs, expression input or MIDI control.

→ Works well with guitar, line and ’pro’ level instruments.

→ In built optional analogue gainstage (+10dB) for low level signals.

→ True relay or buffered DSP bypass with footswitch control and LED indicator.

→ Stereo I/O paths with all Neutrik jacks.

→ Clip level indication LED.

→ Tap Tempo and triggering via footswitch.

Din MIDI input for MIDI beat clock synchronisation and MIDI CC control.

→ All settings remain between power cycles.

→ Factory and user saveable presets per effect.

→ USB-C for quick and easy ‘drag and drop’ firmware updates via computer.

→ Rugged light weight black anodised aluminium enclosure.

2 Year Warranty.

→ Made in England.



Tech Specs

Power: 9V DC power, center negative
Current Draw: 100mA (200mA+ supply recommended)
Input Impedance: 1MOhm
Output Impedance: 1KOhm
Max Input level: +8 dBu (2 Vrms ~ approx 5Vpp)
Optional Gain Stage: +10 dB
Bypass: True Relay & Buffered DSP based
Expression input: 0-3V
Dimensions: 125x65x70mm
16 Bit / 44.1Khz Stereo processing with 32 bit floating point DSP ARM CPU based DSP
