Analog Polyphonic Synthesizer with 3 VCOs, Multi-Mode VCF, Arpeggiator and 16-Step Motion Sequencer
JT MINI
Have the power of a legendary synthesizer anywhere you go when you have the Behringer JT MINI! This super compact, ultra-portable synth comes with a variable waveform VCO, pulse width modulation, a 16-step motion sequencer and is small enough to be tucked away in a backpack or gigbag!
The JT MINI is inspired by the classic Jupiter synth, but we wanted to let you take that sound anywhere, so we decided to shrink everything down and add a bunch more features that make it a real gem in your setup. It features a VCO with 4 selectable waveforms that include saw, triangle, square and pulse. You can also select between Polyphonic or Unison modes, as well as Arpeggio Up, Down, Up and Down or Random
The JT MINI’s VCF section features cutoff and resonance controls while also having the capability to mix in LFO as well as Envelope modulation which can be controlled with the dedicated ADSR sliders. With its 27 touch-sensitive keys, the JT MINI also allows for maximum playability in a small form factor. Combine that with an easily programmable 16-step sequencer, and you’re looking at a versatile, powerful and compact sound shaping machine that’ll easily find a home in your setup.
Specification
Synthesizer Architecture
Number of voices |
3 Voice |
Type |
Analog |
Oscillators |
3 VCO |
LFO |
1 LFO |
VCF |
LPF 12/24 dB/octave |
Envelopes |
1 ADSR |
Connectivity
Power switch |
Push button on/of |
MIDI In |
5-pin DIN / 16 channels |
USB (MIDI) |
USB-C |
Headphones |
3.5 mm TRS, stereo, 5 mW 32 Ω |
Sync |
Input and Output |
USB
Type |
Class compliant USB-C |
Supported Operating Systems |
Windows 7 or higher Mac OS X 10.10 or higher |
Volume
Control |
Volume: 0 to 10 |
Control Section
Switches |
Footage Select - 32', 16', 8', 4', 2', 1' Poly, Uni, Arpeggiator Up, Down, Up & Down, Random |
LFO Section
Controls |
LFO Rate LFO Delay |
Switches (keyboard) |
Waveform: Sine, Saw, Square, random |
Oscillator Section
Controls |
Pitch Mod PWM Mod Detune |
Switches |
Waveform select |
Analog Filter Section
Controls |
Cutoff Resonance LFO Mod Env Mod |
Switches (keyboard) |
Slope: 12 dB/octave, 24 dB/octave |
Sequencer Section
Capacity |
16 steps, 10 patterns |
Control |
Tempo |
Switches |
Memory/Write Function Play/active Record/erase Scale (Keyboard): 1/1, 1/2, 1/4 Metronome On/Of (Keyboard) Step Trigger (Keyboard) Freestyle (Keyboard) Motion Sequence On/Off (Keyboard) Motion Sequence Smooth (Keyboard) Motion Sequence Clear (Keyboard) |
Envelope Section
Sliders |
A(ttack) D(ecay) S(ustain) R(elease) |
Keyboard and Controls
Keyboard |
27, capacitive touch |
Power Requirements
Mains connector |
USB-C |
Indicator |
Power LED |
Physical
Standard operating temperature range |
5°C – 45°C (41°F – 113°F) |
Dimensions (H x W x D) |
43.2 x 193 x 123.7 mm (1.7 x 7.6 x 4.9") |
Weight |
0.38 kg (0.84 lb) |
