Regular price $319.00
/
  • Free shipping over $99 to most states
  • Easy returns
  • Secure payments
  • In Stock
Analog Semi-Modular Synthesizer with Dual VCOs, VCF, Sequencer and Arpeggiator in Eurorack Format
MODEL 15

This is the synth your grandma wish she had! Introducing the Behringer MODEL 15! This compact analog synthesizer features dual VCOs so you can create super-fat bass lines and awesome lead sounds that’ll have everyone in the crowd vibing!

Ready to Go!

The Behringer MODEL 15’s semi-modular design makes it ready to go right out of the box with its 48 patch points at your disposal so you can connect and integrate any module in your collection. And if you were a fan of the legendary System 55, we’ve taken everything great about that and put it in a sleek, compact chassis, so you won’t need a whole truck to transport your setup!

Classic Analog Goodness!

Featuring a pure analog signal path, the MODEL 15 features dual oscillators each with 4 waveforms, pulse width modulation and sub-oscillator. On top of that, the MODEL 15 also comes with 3 separate memory slots for its 256-step arpeggiator with multiple playback modes.

Spring into Action!

Adding reverb to any song, riff or melody is a great way to add depth and character to a piece of music. The MODEL 15 comes with spring reverb emulation that’ll add a sense of space to your music. Couple that with a 4-waveform LFO with adjustable pitch, filter and pulse width modulation and MODELL 15 is capable of lush, intricate and expansive sounds.

Eurorack Ready

The MODEL 15 is designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and mount the module using the included screws. This allows for the MODEL 15 to be mixed with other synth modules for a truly unique set up.

An Amazing Value

Get another sweet addition to your setup plus all the classic tones it comes with by getting a Behringer MODEL 15 today!

Specifications:

Synthesizer Architecture
Number of voices

Monophonic

Type

Analog

Oscillators

2 + sub

LFO

1

VCF

1

Envelope

1 ADSR

Noise

White, pink

Connectivity
Power input

DC input connector

Power switch

Push button on / off

USB (MIDI)

USB 2.0, type B

MIDI in / out / thru

2 x 5-pin DIN / 16 channels

Audio out

1/4" TS, unbalanced, max. +5.8 dBu

Headphones

1/4" TRS, unbalanced, max. 7.5 mW into 32 Ω

Headphones output impedance

8 Ω

Inputs
Type

3.5 mm TS

AUDIO INPUT

Impedance: 280 kΩ -5 V to +5 V

MIX 1

Impedance: 100 kΩ -5 V to +5 V

MIX 2

Impedance: 100 kΩ -5 V to +5 V

MIX 3

Impedance: 100 kΩ -5 V to +5 V

REVERB

Impedance: 150 kΩ -5 V to +5 V

FILTER

Impedance: 100 kΩ -5 V to +5 V

HI PASS

Impedance: 110 kΩ -5 V to +5 V

OSC 1 PWM

Impedance: 100 kΩ 0 V to +5 V

ENV AMT

-8 V to +8 V (DC coupled)

CUT OFF

-5 V to +5 V

OSC 2 FM

Impedance: 90 kΩ -5 V to +5 V

OSC 1 CV

-5 V to +5 V

OSC 2 CV

-5 V to +5 V

ENV TRIG

More than 2.5 V

VCA

Impedance: 100 kΩ -5 V to +5 V

VCA CV

0 V to +8 V (DRONE setting)

LFO TRIG

Impedance: 100 kΩ 0 V to +5 V

LFO RATE

Impedance: 100 kΩ -5 V to +5 V

ATT

Impedance: 110 kΩ -8 V to +8 V

ARP/SEQ SYN

Impedance: 100 kΩ 0 V to +5 V

ARP/SEQ RES

More than 2.5 V

ARP/SEQ ON

off = 0 V / on = +5 V

MULTI 1 (x3)

-5 V to +5 V

LFO Section
Controls

Rate min to max (0.07 Hz - 1.3 kHz)
Pitch mod 0% - 100%
Pulse width 0% - 100%
Filter mod 0% - 100%

Switches

Shape: sine / sawtooth / ramp / square

LED

Rate indication

OSC Section
Controls

Octave 1: 32', 16', 8', 4'
Octave 2: 16' ,8', 4', 2'
Frequency ±7 semitones
Waveform Osc 1: Triangle, sawtooth, square, pulse
Waveform Osc 2: Triangle, sawtooth, square, pulse, sub
triangle, sawtooth, square, pulse
Fine tune ±4 semitones

Buttons

Sync

Mixer Section
Controls

Osc 1 0% - 100%
Osc 2 0% - 100%
Sub / white noise 0% - 100%

Utilities
Controls

Hi pass filter 0% - 100%
max attenuation 36 dBu

Modulation
Control

depth 0% - 100%

Filter Section
Controls

Cutoff frequency: 20 Hz - 20 kHz
Resonance: 0% - 100%
Env amount: 0% - 100%

Switches

Key tracking: 1:2 / off / 1:1

Envelope
Controls

Attack: 2 mS to 16 S
Decay: 2 mS to 40 S
Sustain: 0 to 8 V
Release: 2 mS to 20 S

Reverb
Reverb

Mix 0 - 100%

Output Section
Control

Volume 0% - 100%

Switches

VCA mode env, release, on
