version 2 of the DrumDokta

sound core based on the original drumdokta but a lot quieter noise floor
bass drum,snare drum, open hat, closed hat, cymbal and clap included
built in Optodist JR vactrol distortion/limiter in collaboration with RYO
8 track sequencer with up to 64 step tracks, in collaboration with Sonic Potions (LXR)
each track can have its own independent last step (poly rhythms galore)
6 aux trigger outs
clock in, reset, cv over snappy, cv over bpf.
16 pattern memories x 8 tracks x 64 steps with data retention (with 1000 auto saves a day the eeprom should last about 65 years)

• 36HP Wide
• 50 mA +12V
• 10 mA -12V
• 0 mA 5V
• 30 mm Depth
