• 30 HP width, up to 1" in depth (super slim and therefore skiff friendly)
• All analog signal path inspired by and based on famous west coast synthesis — a module within the idea of harmonic generation based on additive synthesis theory
• 2 discrete OTA triangle-core VCOs both with hard- (resetable) and soft- (inverting) syncs. The cores are self made custom encapsulated circuits with decent results of tracking (up to 6 octaves) as well as fine temperature stability
• Selectable tracking (1 or 1.2 v/oct) by setting a jumper (we believe at last a few wigglers will appreciate that)
• Bolted potentiometers, wobble free for heavy duty
• Multi-turn frequency knobs sweep up to 10 octaves
• Oscillator tuners that simply always work
• Of course, RoHS and cat friendly

The harmonical section of the carrier oscillator involves a complex chain of waveshapers, crossfaders, wavefolder as well as the "Mood Index" with amplitude-, balanced-, frequency- and timbre-modulation.
Every parameter is voltage controlled, interacts with and depends on each others position.
The whole scheme is a bit complex for immediate understanding. We consider the better way to understand it, is to start with forgetting about the waveforms – just explore it.

http://furthrrrr.endorphin.es/

• 30hp
• 200 mA +12V
• 200 mA -12V
• 0 mA 5V
• 18 mm Depth
