• 12 HP/TE width, up to 35mm ca. 1.5” in depth (super slim & therefore shuttle friendly)
• 12 bit USB-to-MIDI-to-CV converter module with 16 arbitrary assignable channels
• simultaneous USB on-the-go device and host modes using 120 MHz 32-bit ARM Cortex™-M3 CPU
• internal PSU capable of working from cigarette lighter receptacle, rechargeable battery or 12-20V AC-DC power adapter
• no drivers are required for a direct connection to your MAC/PC or iOS devices
• up to 8 voices of polyphony, polyphonic key aftertouch, no steps in CC voltages, MIDI clock, Tap Clock, Tap LFO, bi-directional USB-MIDI transfer and many more MIDI events can be translated into CV

Shuttle Control consists of the following parts:
• Switched mode PSU
• USB-to-MIDI-to-CV converter
• Web-based editor for editing presets

• 12hp
• 120 mA +12V
• 80 mA -12V
• ? mA 5V
• 35 mm Depth

Manual
