Joystick w/Trigger & Gate

The Choices joystick module was designed to pack as much utility as possible in as little space as possible while keeping the price as low as possible, keeping with the design philosophy of f(h). Here are the basic features and uses: Moving the joystick operates two 100k potentiometers simultaneously, providing a buffered DC Control Voltage (CV) to the outputs; the X output varies with horizontal motion, the Y with vertical motion. Switched phone jacks disconnect the internal control connection from the power supply to the jack when an external signal is connected to an input.

Inputs
• X/Y

Outputs
• X/Y
• Gate
• Trigger

Controls
• Joystick
• Scale (0-200%)
• Offset (Bias)
• Ref (DC/AC Switch)
• Trigger/Gate Button (2)

Physical Specifications
• Format: Eurorack
• Width: 14HP
• Depth: 1.4″

Electrical Specifications
• Power: +12V @ 14.1mA, -12V @ 13.7mA
