KLAVIS CALTRANS

KLAVIS CALTRANS

Price
Regular price $19800
Regular price Sale price $19800
/
  • Free shipping over $99 to most states
  • Easy returns
  • Secure payments
Shipping calculated at checkout.
  • Four V/Oct processing channels, each with

    • Curve correction and range expansion for any VCO, VCF or other oscillating circuit with a CV acting on the pitch
    • Switchable semitone quantizer
    • Adjustable portamento time
    • Adjustable glissando time
  • Separate semitone and octave transpose encoders
  • Inputs cascading with no added load for stable pitch control
  • Four user presets storing transpose, portamento, and glissando
  • Storage of the calibration profile for each channel
  • Maximum voltage range covering 10 octaves
  • Presets, calibration and current state retained over power cycle
  • Volt/Oct inputs factory-calibrated in flash memory
  • Easy firmware update via a simple audio file
  • High-quality push-encoders with metal shaft
  • Skiff-friendly & compact module
SPECIFICATIONS
  • 6hp
  • 39 mA +12V
  • 8 mA -12V
  • 0 mA 5V
  • 36 mm deep
