Multiple Control Modes.
MultiSwitch Plus can be configured in several different ways to extend floor control of compatible Strymon pedals. Depending on the selected mode and the pedals connected, you can recall presets, change banks, operate TimeLine’s looper, remotely tap tempos, and more. See compatibility chart below.
Control up to Three Pedals.
Featuring three outputs, MultiSwitch Plus allows you to connect up to three compatible Strymon pedals using additional TRS cables (sold separately). Now you can engage presets on three compatible pedals simultaneously (Compadre, Iridium, Riverside, Sunset, and Volante). Or mix and match the footswitches to set up your own custom operation—such as controlling tap tempo on your Flint, Favorite on your El Capistan, and Boost on your Riverside.
Instant Preset Access
Add a MultiSwitch Plus to your Compadre, Iridium, Riverside, Sunset, or Volante and gain instant access to presets 1, 2, and 3. Or connect three pedals to MultiSwitch Plus using additional TRS cables (sold separately) to access three synchronized presets on three pedals simultaneously.
Compatibility
Mode | Description | Compatibility |
Preset Mode | Adds the ability to select and bypass onboard presets 1, 2, and 3. | Compadre, Iridium, Riverside, Sunset, Volante |
Custom Mode | Provides remote access to Volante’s Speed switch, and enhances transport controls. | Volante |
TimeLine, BigSky, and Mobius Mode | Expanded preset selection control. Dedicated looper controls (TimeLine). | BigSky v1.49, Mobius v1.39, TimeLine v1.87 |
Tap/ Fav/ Boost/ Speed Mode | Each footswitch is paired with the closest output and its function can be independently assigned. |
Tap: BigSky, Deco, DIG, Flint, Mobius, Timeline, Volante Fav: Brigadier, Compadre, Deco, DIG, El Capistan, Flint, Iridium, Lex, Riverside, Sunset Boost: Riverside Speed: Lex |
Combo Mode | Footswitches A and B will select between presets 1 and 2 for pedals connected to outputs 1 and 2. Footswitch C can be used for remote tap tempo, favorite, boost, or speed for the pedal connected to output 3. |
Presets: Compadre, Iridium, Riverside, Sunset, Volante Tap: BigSky, Deco, DIG, Flint, Mobius, Timeline, Volante Fav: Brigadier, Compadre, Deco, DIG, El Capistan, Flint, Iridium, Lex, Riverside, Sunset Boost: Riverside Speed: Lex |
-
Specs
- 1/4″ right-angle TRS cable included
- No additional power supply required
- Rugged black anodized aluminum chassis
- Small and lightweight
- Designed and built in the USA
- FAQ
-
-
What is the difference between MultiSwitch Plus and MultiSwitch?
MultiSwitch Plus offers all of the functionality of MultiSwitch, but provides additional compatibility options, three outputs for connecting multiple Strymon pedals, and LEDs.Is a cable included?
Yes, MultiSwitch Plus comes with one 1/4″ right angle TRS cable.Can’t I use a MIDI controller to access some of these functions?
Certainly—if you’d like, you can access these features using MIDI. MultiSwitch Plus is geared towards those that don’t want or don’t need to use MIDI in their rigs. MultiSwitch Plus is connected via a standard TRS cable and does not require a separate power supply.Do I need to update the firmware on my TimeLine, BigSky, Mobius, Sunset, Riverside, or Volante to use MultiSwitch Plus?
In some cases yes. Please visit strymon.net/update for information on how to check your firmware version, and how to update your firmware. All TimeLine, Mobius, and BigSky pedals built as of February 1, 2019 will ship with firmware that is compatible with MultiSwitch Plus. If your TimeLine, Mobius, or BigSky was built before this date then it will require a firmware update.How do the LEDs function in the different modes?
Depending on how MultiSwitch is configured, the LEDs indicate the currently loaded preset or the status of the Boost or Speed setting for connected pedals. The LEDs do not function in Timeline, BigSky & Mobius mode because communication with TimeLine, BigSky and Mobius via the EXP jack is not bi-directional. Custom mode LED functionality varies depending on the connected pedal and how it is configured.What pedals are compatible with MultiSwitch?
Please see Compatibility Chart above.
-
